Stainless Steel 304L Plate, ASTM A240 Type 304L Sheet and AISI 304L Coil

What is Stainless Steel 304L Plate?

Stainless Steel 304L Plate is a lower carbon version of the austenitic 304 grade. The lower carbon content in this plate eliminates graining and carbon precipitation after the welding process. The chromium-nickel austenitic grade is a corrosion-resistant alloy that is well suited for a range of high-temperature and pressure systems. The plate is non-magnetic in the annealed condition but becomes magnetic after cold rolling or welding procedures.

ASME SA 240 Grade 304L Stainless Steel Sheet Application

ASME SA 240 Grade 304L Stainless Steel Sheet is a versatile component that is utilized in different applications. Some of the main applications include:

Food and beverage processing systems
Chemical industries
Processes in pressure vessels, heat exchangers, valves, fittings, and pumps
Petroleum refining
Pharmaceuticals
Nuclear power generation
Pulp and paper
Mining systems

Difference Between UNS S30403 Coil and AISI 304L Strips

Coils and strips form an integral component of welding a range of piping equipment. The major differentiating factor is the width of both these metal modules

A UNS S30403 Coil in a piping system is coiled after the rolling process. This allows them to be transported efficiently from one place to the other. The width of a coil is not less than 600mm
AISI 304L Strips are metal components that are sheared from a coil. These strips are shaped in a range of sizes and shapes. Strips are designed with a width of less than 600mm.

WNR 1.4307 Foil Vs SS TP 304L Shim Sheets

304L is a low-carbon alloy that can be formed in different components. Foils and shim sheets are amongst a few shapes the metal in this grade can be shaped into.

A SS TP 304L Shim Sheets are utilized in systems to fill gaps and spaces in between a range of components. The gaps ensure that they provide stability and support to the entire module. Shims are designed with thicknesses of over 0.020mm.
Foils are metal components that are rolled or hammered. These foils can be bent, rolled, or used to cover equipment to give it protection and insulation. Foils are generally available in thickness below 0.2mm.

Table of Content

Stainless Steel 304L Strips

ASTM A240 Grade 304L

304L Plate Specification

Product Type	SA240 304L Sheet, SA240 304L Plate
Specification	ASTM A240 / ASME SA240
Tolerances (width / thickness)	EN 10258/ DIN 59381) EN 10151 ASME SA 240 304L Strips EN 10088 SA 240 Gr 304L strips
International Standard	ASTM A 480 ASTM A 959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510
Size Range	Cold rolled ASME SA 240 Grade 304L SS Sheet 0.5-6.4 mm Hot rolled ASME SA 240 Grade 304L SS Sheet 3.0–10.0 mm
Thickness	0.1 to 100 mm Thk
Width	10-2500mm
Length	2m, 2.44m, 3m, or as required
Finish	2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc.
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard
Form	Plate, Sheet, Coils, Foils, Strip, Flats, Clad Plate, Plain Sheet, Rolling Sheet, Rolling Plate, Flat Shim, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), sheared, annealed, soft annealed, descaled, tread plate, Checker Plate
Stainless Steel 304L Plate Supplier In India

Looking for Tp 304L Sheets suppliers who offer prompt delivery in Asia? Manufacturer of UNS S30403 2d SS 304L Cold Rolled Plates in India, call us for big discount and ready sizes, check latest price of WNR 1.4307 Material in Mumbai

ASTM A240 Type 304L Sheet And AISI 304L Coil Manufacturer And Supplier In India, Check Stainless Steel 304L Foil Thickness

304L Stainless Steel Sheet Thickness

Thickness: 0.2 - 50 mm. Grade: SS304 L.

Tp 304L Sheets Equivalent

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
SS 304L	S30403	1.4306/1.4307	Z3CN18‐10	X2CrNi18-9 / X2CrNi19-11	SUS 304L	304S11	03Х18Н11

Stainless Steel 304L Sheet Available For Online Order, Buy TP 304L Strips and SS 304L Plate Price in India

304L Stainless Steel Plate Price

Description	Price In (INR)	Price In (US)
6mm thick NO.1 AISI 321 304L stainless steel sheet	60002.10 - 135098.60	US $799.00 - US $1,799.00/ Ton
AISI 304L stainless sheet and plate	150193.00	US $2,000.00/ Ton
ASME SA240 304L stainless plate	150193.00 - 187741.25	US $2,000.00 - US $2,500.00/ Ton

Manufacturer & Supplier Of AISI 304L Strips, AISI 304L Sheets In India

Stainless Steel 304L Coil Chemical Composition

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
304L	min.	–	–	–	–	–	18.0	–	8.0	–
304L	max.	0.030	2.0	0.75	0.045	0.030	20.0	–	12.0	0.10

Physical Properties Of Stainless Steel 304L Plate

Grade	Density (kg/m3)	Elastic Modulus (GPa)	Mean Coefficient of Thermal Expansion (m/m/0C)			Thermal Conductivity (W/m.K)		Specific Heat 0-1000C (J/kg.K)	Electrical Resistivity (n.m)
			0-1000C	0-3150C	0-5380C	at 1000C	at 5000C
304L	8000	193	17.2	17.8	18.4	16.2	21.5	500	720

Stainless Steel 304L Strips Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
304L	485	170	40	92	201

AISI 304L Sheets Thermal Properties

Temperature Range
°F	°C	in/in °F	cm/cm °C
68-212	20-100	9.2 x 10-6	16.6 x 10-6
68-932	20-500	10.6 x 10-6	18.2 x 10-6
68-1600	20-870	11.0 x 10-6	19.8 x 10-6

Processing Of 304L Stainless Steel Strip

Well-known Supplier Of SS 304L Shims in India. For final Stainless Steel Type 304L Foil Price List Please Call on +91 22 6636 3099.

Test Certificates Of Stainless Steel Type 304L Foil

EN 10204/3.1B,
Raw Materials Certificate
100% Radiography Test Report
Third Party Inspection Report, etc

Buy SS 304L Perforated Sheet Directly From Largest Supplier In Mumbai, Check Weight Chart Of Sa240 304L Plates

Pay Only For The Sizes You Buy Of SA 240 Type 304L Material And UNS S30403 2d stainless steel cold rolled/ hot rolled Plate

SS 304L Shims Size Chart

Sizes in inch	Sizes in MM
.134	3.40
.187	4.75
.156	3.96
.250	6.35
.375	9.53
.312	7.92
.500	12.7
.750	19.1
.625	15.9
.875	22.2
1.125	28.6
3	76.2
1	25.4
1.250	31.8
1.750	44.5
1.500	38.1
2	50.8
3	76.2
2.500	63.5
.125	3.18

304L Stainless Steel Plate Weight

Thickness in Inch	Plate Weight per lbs/in² and kg/m²	Density lbs/in³ g/cm³
3	0.941 / 661.5884936	0.315 / 8.72
3/16	0.06000 / 42.184176	0.315 / 8.72
3/8	0.121 / 85.0714216	0.315 / 8.72
1/2	0.161 / 113.1942056	0.315 / 8.72
1/4	0.08 / 56.245568	0.315 / 8.72
5/8	0.196 / 137.8016416	0.315 / 8.72
3/4	0.235 / 165.221356	0.315 / 8.72
7/8	0.274 / 192.6410704	0.315 / 8.72
1	0.313 / 220.0607848	0.315 / 8.72
1 1/4	0.391 / 274.9002136	0.315 / 8.72
1 3/4	0.549 / 385.9852104	0.315 / 8.72
2	0.627 / 440.8246392	0.315 / 8.72
1 1/2	0.47 / 330.442712	0.315 / 8.72
2 1/2	0.784 / 551.2065664	0.315 / 8.72
2 3/4	0.862 / 606.0459952	0.315 / 8.72
2 1/4	0.705 / 495.664068	0.315 / 8.72

SS 304L Perforated Sheet Marking

Rating Designation
Material Designation
Specification Number
Grade
Length
Manufacturer’s Name or Symbol

PED Certified Stainless Steel 304L Plate Supplier in Mumbai, India, Dimensions Of 304L Plate In MM.

Stainless Steel 304L Sheet Dimension

Surface finish	Thickness in Mm	Width in MM
2B=Cold rolled, pickled, heat treated, skin passed	0.25 To 8.0	maximum 2032
Polished, brushed	0.5 To 4.0	maximum 1524
2D=heat treated, pickled, Cold rolled	0.4 To 6.35	maximum 1524
2E=Cold rolled, mechanically descaled, heat treated	0.4 To 8.0	maximum 2032
2H=hardened	0.4 To 6.35	maximum 1524
2R=bright annealed, Cold rolled	0.25 To 3.5	maximum 1524

Types Of UNS S30403 Polished Plates

Stainless Steel 304L Coil

Stainless Steel 304L Sheet

Cold Rolled ASTM JIS 304L Stainless Steel

304L 2b Finish Stainless Steel Sheet / Plate

Stainless Steel 304L Plate

304L Stainless Steel Sheet Plate

304L Hot Rolled Stainless Steel Plate

16 Gauge 304L Stainless Steel Plate

ASTM A240 Grade 304L 6mm Stainless Steel Checkered Plate

3mm Thick 304L Stainless Steel Sheet

Stainless Steel 304L Shim Sheet

We Keep Bulk Stock Of 304L Stainless Steel Sheet At Our Stockyard, Contact Us For Free Sample & Stock List

ASTM A240 Grade 304L Plate Stock

Stainless Steel 304L Chequered Plate	Stainless 1.4306 Quarto Plate
UNS S30403 Sheet	304L SS Tisco Plate
ASME SA240 304H Chequer Plate	304H Stainless Tread Plate
SS A240 304L Checker Plate	ASTM A240 304H Strip
304H Stainless Plate Brushed Finish	SS 304L Hot Rolled Sheet
Stainless 304L 10mm Shim	Stainless Steel 1.4306 Cold Rolled Sheet
304H Stainless Steel 1/4 Inch Coil	ASTM A240 304H Perforated Sheet
ASTM A240 304H Plate	304L SS Rolling Plate
Stainless 1.4306 Hot Rolled Plate	304H Stainless Steel Foil
304L SS Cold Rolled Plate	SS A240 304L Bbq Plate
304H Stainless Plate 2b Finish	UNS S30403 Coil
SS A240 304L Plate Mill Finish	ASME SA240 304H Strip Tape
ASTM A240 304H Custom Cut Plate	ASTM A240 304L Sheet
304L SS Shim	Stainless Steel 304L Laser Cut Plate
304H Stainless Embossed Sheet	ASTM A240 304H Perforated Sheet

Check Thickness Of 304L Stainless Steel Hot Rolled Plates and UNS S30403 Polished Plates Supplier & Manufacturers In Mumbai, India.

304L Stainless Steel Plate Thickness

Thickness	Thickness	Size Chart	SS 304L Plate Approx Weight		SS 304L Plate Unit weight
milimeter	inches		lbs	Kilogram	lbs/ft²	kg/m²
0.381	0.015	36 x 96	15.12	6.84936	0.630	3.07566
0.381	0.015	36 x 120	18.90	8.5617	0.630	3.07566
0.45212	0.0178	36 x 96	18.15	8.22195	0.756	3.690792
0.45212	0.0178	36 x 120	22.68	10.27404	0.756	3.690792
0.45212	0.0178	48 x 96	24.19	10.95807	0.756	3.690792
0.45212	0.0178	48 x 120	30.24	13.69872	0.756	3.690792
0.5969	0.0235	30 x 96	20.16	9.13248	1.008	4.921056
0.5969	0.0235	30 x 120	25.20	11.4156	1.008	4.921056
0.5969	0.0235	36 x 96	24.19	10.95807	1.008	4.921056
0.5969	0.0235	36 x 120	30.24	13.69872	1.008	4.921056
0.5969	0.0235	36 x 144	36.29	16.43937	1.008	4.921056
0.5969	0.0235	48 x 96	32.26	14.61378	1.008	4.921056
0.5969	0.0235	48 x 120	40.32	18.26496	1.008	4.921056
0.5969	0.0235	48 x 144	48.39	21.92067	1.008	4.921056
0.73914	0.0291	30 x 96	25.20	11.4156	1.260	6.15132
0.73914	0.0291	30 x 120	31.50	14.2695	1.260	6.15132
0.73914	0.0291	36 x 96	30.24	13.69872	1.260	6.15132
0.73914	0.0291	36 x 120	37.80	17.1234	1.260	6.15132
0.73914	0.0291	36 x 144	45.37	20.55261	1.260	6.15132
0.73914	0.0291	48 x 96	40.32	18.26496	1.260	6.15132
0.73914	0.0291	48 x 120	50.41	22.83573	1.260	6.15132
0.73914	0.0291	48 x 144	60.49	27.40197	1.260	6.15132
0.9017	0.0355	30 x 96	30.24	13.69872	1.512	7.381584
0.9017	0.0355	30 x 120	37.80	17.1234	1.512	7.381584
0.9017	0.0355	36 x 96	36.29	16.43937	1.512	7.381584

SS 304L Plate In Cut To Sizes, Supplier Of 304L Stainless Steel Strip As Per International Standard

ASTM A240 Grade 304L Material Standard

UNS S30403
AMS 5511
AMS 5513
ASTM A 240
ASTM A 276

W.NR 1.4307
PWA-LCS
GE Aircraft Engine (GT193)
GE Aviation S-SPEC-35 AeDMS S-400

RR SABRe Edition 2
ASTM A 479
ASTM A 484
ASME SA 240
DFARS Compliant

Get instant delivery Of 20mm A240 304L Stainless Steel Coils , Tolerance Chart Of ASTM A240 Gr 304L Chequered Plate, Stainless Steel 304L Sheet Supplier In India.

ASTM A240 Gr 304L Chequered Plate Tolerance

Thickness - Inch	Gauge	Tolerance*
.1875 to .1451	8 & 9	.007
.1451 to .1301	10	.006
.1301 to .1141	11	.005
.1141 to .0981	12	.005
.0981 to .0831	13	.004
.0831 to .0721	14	.004
.0721 to .0581	15 & 16	.003
.0581 to .0401	17 to 19	.003
.0401 to .0291	20 to 22	.002
.0291 to .0160	23 to 27	.0015
