- Cold rolled Ti Alloy Plate : 0.5-6.4 mm
- Hot rolled Alloy Titanium Plate : 3.0–10.0 mm
- Titanium Wrought Alloy Sheet : 0.01~200mm
We are a complete range of titanium sheet suppliers and stockiest with mill test certificates for complete traceability. We stock in a wide variety of grades and sizes that fit a wide range of specifications.
Titanium Sheet is 30% stronger and 50% lighter compared to steel. And 60% heavier compared to aluminum, but twice as strong. It is alloyed with aluminum, manganese, molybdenum, iron, and other metals in order to increase its strength, to resist high temperatures, and to lighten the effect alloy. Its high corrosion resistance is a valuable characteristic; as when it is exposed to the atmosphere, it forms a tight, firm oxide film that resists many corrosive materials, especially salt water.
Titanium Sheet Grades
Titanium Grade 1 is the softest, most ductile which is especially easy to work with due to its excellent formability. It acceptable to marine and chemical processing applications due to its high corrosion resistance. And it can also resist high-impact environments.
Titanium Grade 2 is slightly stronger than titanium grade 1 and it is frequently utilized for architecture and medical applications, as it can be simply formed and welded.
Titanium Grade 3 is less flexible than titanium Grade 1 and 2, it is used less frequently compared to grade 1 and 2 but it is perfect for application which needs medium strength and high corrosion resistance, such as aerospace and medical applications.
Titanium Grade 4 is the strongest commercially pure unalloyed grades, it is also highly formable, weldable and corrosion resistant. It is commonly used in industries where high strength is needed, such as aerospace and medical.
Titanium Grade 5 is composed of aluminum, iron, oxygen and vanadium. It is considered as most popular titanium alloy. It has good formability, high strength but light in weight, good formability, high corrosion and creep resistance and superior toughness. It is predominantly used in airframe and turbine engine parts; and for use in surgical implants.
Titanium Grade 9 is exceptionally corrosion resistant. While it is not as strong as grade 5, but it is still used in aerospace and industrial applications it is light in weight and greater resistant to high temperature.
Titanium Grade 23 is an alloyed titanium product containing aluminum 6% and vanadium 4%.
Table of Content
ASTM B348 Titanium Plate Price
Price list of Titanium Plate | Price in INR | Price in USD | Price in UAE Dirham |
---|---|---|---|
Pure Titanium Grade 5 Plate |
INR 1739 | 23.02 USD | 84.57 UAE Dirham |
Titanium Grade 2 Plate |
INR 1,858 | 20.07 USD | 95.94 UAE Dirham |
Titanium Plate Specification
ASTM Specification | ASTM A240 / ASME SA240 |
---|---|
Standard | MSRR, AMS, BS, ASTM A240 / ASME SA240 |
Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1250mm x 2500mm, 1500mm x 3000mm to 6000mm, 2000mm x 4000mm to 6000mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 2m, 2.44m, 3m, 36" X 120" or 48" X 144", 4' x 8', Cut to size available |
Thickness | 0.1mm to 100 mm Thk |
Width | 10-2500mm |
Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Temper | Annealed |
Condition | Polished on both sides |
Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Stock in form of | Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
Test Report |
|
Profiling | To provide a full profiling service we use numerous profiling methods including:
|
Specialized in |
|
We offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing. |
Titanium Grade 5 Plate Thickness
Thickness | Grades |
.040 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.050 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.063 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.071 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.080 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.016 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.020 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.025 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.032 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.090 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.100 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
.125 | CP1, 55A, 6AL-4V ANN, A70, CP3, A40, 75A |
Get instant delivery Of 2 Inch Uns R50400 Cold Rolled Clad Plates, Grade 2 Titanium Foil Suppliers In Mumbai, India.
Titanium Alloy Grade 2 Sheet Size Range
- Cold rolled Ti Alloy Plate : 0.5-6.4 mm
- Hot rolled Alloy Titanium Plate : 3.0–10.0 mm
- Titanium Wrought Alloy Sheet : 0.01~200mm
Ti Gr 5 Shim Sheets Size
Titanium Sheet Manufacturers In India | ||
---|---|---|
Thickness (in) | Size (in) | Appx. Weight Per Sheet (lbs) |
.016 | 36 x 96 | 8.8 |
.020 | 36 x 96 | 11.0 |
.025 | 36 x 96 | 13.8 |
.032 | 36 x 96 | 17.7 |
.040 | 36 x 96 | 22.1 |
.050 | 36 x 96 | 27.7 |
.063 | 36 x 96 | 34.9 |
.071 | 36 x 96 | 39.3 |
.080 | 36 x 96 | 44.2 |
.090 | 36 x 96 | 49.8 |
.100 | 36 x 96 | 55.3 |
.125 | 36 x 96 | 69.1 |
.160 | 36 x 96 | 88.5 |
.187 | 36 x 96 | 103.4 |
Cp Grade 2 Titanium Sheet Supplier in Mumbai | ||
---|---|---|
Thickness (in) | Size (in) | Appx. Weight Per Sheet (lbs) |
.020 | 48 x 120 | 18.8 |
.028 | 48 x 120 | 26.3 |
.035 | 48 x 120 | 32.9 |
.040 | 48 x 120 | 37.6 |
.050 | 48 x 120 | 46.9 |
.063 | 48 x 120 | 59.1 |
.078 | 48 x 120 | 73.2 |
.093 | 48 x 120 | 87.3 |
.125 | 48 x 120 | 117.4 |
Dimension Of Uns R50400 Cold Rolled Plates
Titanium Alloy Sheet Metric Dimensions
Surface finish | Thickness (mm) | Width (mm) |
---|---|---|
2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
2H – Work hardened | 0.4–6.35 | max. 1524 |
Polished, brushed | 0.5–4.0 | max. 1524 |
Imperial Dimensions of Titanium Alloy Sheet
Surface finish | Gauge (in) | Width (in) |
---|---|---|
2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | max. 72* |
2D – Cold rolled, heat treated, pickled | 12–24 | max. 60 |
BA Mexinox only | 18–28 | max. 48 |
Polished (not brushed) | 11–24 | max. 60 |
Temper rolled Mexinox only | 13–29 | max. 48 |
Titanium Grade 2 Plate Weight
Thickness | Plate Weight per Unit Area | Density |
---|---|---|
3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Titanium Strips For Sale
Titanium Chequered Plate | Titanium Super Alloy Quarto Plate |
Titanium Steel Alloy Sheet | Titanium Wrought Alloy Tisco Plate |
Alloy Titanium Chequer Plate | Ti Alloy Tread Plate |
Titanium Checker Plate | Titanium Alloy Strip |
Ti Alloy Plate Brushed Finish | Titanium Alloy Hot Rolled Sheet |
Titanium 10mm Shim | Titanium Super Alloy Cold Rolled Sheet |
Ti Alloy 1/4 Inch Coil | Titanium Alloy Perforated Sheet |
Titanium Alloy Plate | Titanium Wrought Alloy Rolling Plate |
Titanium Super Alloy Hot Rolled Plate | Ti Alloy Foil |
Titanium Wrought Alloy Cold Rolled Plate | Titanium Bbq Plate |
Ti Alloy Plate 2b Finish | Titanium Steel Alloy Coil |
Titanium Plate Mill Finish | Alloy Titanium Strip Tape |
Titanium Alloy Custom Cut Plate | Ti Alloy Sheet |
Titanium Wrought Alloy Shim | Titanium Laser Cut Plate |
Ti Alloy Embossed Sheet | Titanium Alloy Perforated Sheet |
Prestige quality Titanium Sheet Suppliers In India offer in EN, DIN, ISO, BS, JIS or ANSI standard.
Grade 5 Titanium Sheet Standard
SHEET, PLATE & COIL | ||
---|---|---|
Sizes: Sheet & Plate .012 TO 4.00 X r/w X R/L Sizes: Coil .001 to .011 x R/W x R/L | GRADE | SPECIFICATIONS |
6AL-4V, 6AL-4V ELI | AMS-4911, 4907,4905, MIL-T-9046, ASTM-F136 | |
DMS-1592, GM-3103,12TM-B265 | ||
6AL-2SN-4ZR-2MO | AMS,4919, MIL-T-9046, DMS-2275, AMS-T-9046 | |
GM-3104, B50TF21 | ||
6AL-6V-2SN | AMS-4918, MIL-T-9046, DMS-1879, AMS-T-9046 | |
5AL-2.55N, 5-2.5 ELI | AMS-4909, 4910, MIL-T-9046, AMS-T-9046 | |
BAL-IMO-1V | AMS-4915, 4916, DMS-1784 | |
CP-GRADES 1,2,3,4 | AMS-4900, 4902 | |
MIL-T-9046, AMS-T-9046, DMS-1536, ASTM-B265 | ||
15V-3CR-3SN-3AL | AMS-4914 |
Cp Grade 4 Titanium Sheet Distributors
Types Of Titanium Sheet
SP Metals is an ISO certified Titanium Plate Suppliers In India & Grade 5 Titanium Sheet distributor in Mumbai
Ams Specification Of Ams 4901 Sheet
AMS | Properties |
---|---|
4900L | Strip, Sheet and Plate, 55.0 ksi (379 MPa) Yield Strength, C.P., Annealed |
4901M | Strip, Sheet and Plate, 70.0 ksi (485MPa), C.P. Annealed |
4902G | Strip, Sheet and Plate, 40.0 ksi (276 MPa) Yield Strength,C.P. Annealed |
4905B | Beta, Damage-Tolerant Grade Plate 6AL – 4V, Annealed |
4917E | Strip, Sheet and Plate, 13.5V – 11Cr – 3.0AL, Solution Heat Treated |
4918H | Strip, Sheet and Plate, 6AL – 6V- 2Sn Annealed |
4907F | Extra Low Interstitial Annealed, Strip, Sheet and Plate 6AL-4V, |
4909F | Strip, Sheet, and Plate 5AL -2.5Sn, Annealed, Extra Low Interstitial |
4908F | 8Mn, Sheet and Strip, 110,000 psi (760 MPa) Yield Strength, Annealed |
4911H | Strip, Sheet and Plate, 6AL – 4V, Annealed |
4915G | Strip, Sheet and Plate, 8AL – 1V – 1Mo, Single Annealed |
4914A | Cold Rolled Sheet and Strip, 15V - 3AL – 3Cr – 3Sn Solution Heat Treated |
4910K | Strip, Sheet and Plate 5AL – 2.5Sn Annealed |
4916F | Strip, Sheet and Plate, 8AL – 1Mo – 1V, Duplex Annealed |
4919C | Strip, Sheet and Plate, 6AL– 2Sn – 4Zr – 2M0 – 0.08Si, Duplex Annealed |
Titanium Coil Chemical Composition
Titanium Grade | 1 | 2 | 3 | 4 | 5 | 7 | 9 | 12 |
---|---|---|---|---|---|---|---|---|
C Max | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 | 0.08 |
O Max | 0.18 | 0.25 | 0.35 | 0.40 | 0.20 | 0.25 | 0.15 | 0.25 |
N Max | 0.03 | 0.03 | 0.05 | 0.05 | 0.05 | 0.03 | 0.03 | 0.03 |
H Max | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 | 0.015 |
Iron Max | 0.20 | 0.30 | 0.30 | 0.50 | 0.40 | 0.30 | 0.25 | 0.30 |
Al | ... | ... | ... | ... | 5.5~6.75 | ... | 2.5~3.5 | ... |
V | ... | ... | ... | ... | 3.5~4.5 | ... | 2.0~3.0 | ... |
Mo | ... | ... | ... | ... | ... | ... | ... | 0.6~0.9 |
Ni | ... | ... | ... | ... | ... | ... | ... | 0.2~0.4 |
Pd | ... | ... | ... | ... | ... | 0.12~0.25 | ... | ... |
Other Max | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
Total Max | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 |
Titanium Plate Manufacturers In India, Suppliers Of Ti Gr 5 Shim Sheets In Mumbai, One Stop Shop For All Cp Grade 4 Titanium Sheet.
Mechanical Properties Of Cold Rolled Titanium Plates
Grade | Tensisle Strength | Yield Strength |
Elogation in 2 in. or 50mm min.,% |
Bend Test | |||||
---|---|---|---|---|---|---|---|---|---|
Min | Min | Min | Min | Max | Max |
Under 0.070 in. (1.8mm) Thickness |
0.070 to 0.187 in. (1.8mm to 4.75mm) Thickness |
||
Ksi | Mpa | Ksi | Mpa | Ksi | Mpa | ||||
1 | 35 | 240 | 20 | 138 | 45 | 310 | 24 | 1.5T | 2T |
2 | 50 | 345 | 40 | 275 | 65 | 450 | 20 | 2T | 2.5T |
3 | 65 | 450 | 55 | 380 | 80 | 550 | 18 | 2T | 2.5T |
4 | 80 | 550 | 70 | 483 | 95 | 655 | 15 | 2.5T | 3T |
5 | 130 | 895 | 120 | 828 | ... | ... | 10 | 4.5T | 5T |
7 | 50 | 345 | 40 | 275 | 65 | 450 | 20 | 2T | 2.5T |
9 | 90 | 620 | 70 | 483 | ... | ... | 15 | 2.5T | 3T |
12 | 70 | 483 | 50 | 345 | ... | ... | 18 | 2T | 2.5T |
COMMERCIALLY PURE TITANIUM SHEET | |||
---|---|---|---|
GRADE | BRITISH STANDARD | FRANCE | GERMAN AEROSPCE |
GR.1 | BS 2TA 1 | T-35 | 3.7024 |
GR.2 | BS 2TA 2 | T-40 | 3.7034 |
GR.3 | DTD5023 | T-50 | 3.7054 |
GR.4 | BS 2TA 6 | T-60 | 3.7064 |
ISO Approved Grade 5 Titanium Coil Supplier In India. Also Check Titanium Alloy Grade 2 Chequered Sheet Equivalent Properties
Ti-6al-4v Sheet Equivalent
STANDARD | WERKSTOFF NR. | UNS |
Titanium Gr. 2 | 3.7035 | R50400 |
Titanium Gr. 5 | 3.7165 | N56400 |
Ti-6al-4v Titanium Foil Manufacturers In Usa | |
---|---|
Grade | Specification |
C.P.1, A70, 75A | AMS-4901 / MIL-T 9046, TYPE 1 COMP. B / C.P.1, DMS 1536 |
C.P.3, A40, 55A | AMS-4902 / MIL-T 9046, TYPE 1 COMP. A / C.P.3 |
6AL-4V ANN | AMS-4911 / MIL-T 9046, TYPE 3 COMP.C / AB1, DMS 1592 |
Processing Of Titanium Foil
ASTM B265 Grade 5 Sheet Surface Finish
SP Metals is an ISO certified Titanium Strip Suppliers in India & Ams 4901 Sheet Stockist in Mumbai.
Titanium Shim Sheets Gauge Chart
Gauge Number | MM | Inches |
8 | 4.0365 | .017187 |
9 | 3.0968 | .015625 |
10 | 3.0571 | .014062 |
11 | 3.0175 | .0125 |
12 | 2.0778 | .010937 |
14 | 1.0984 | .007812 |
16 | 1.0587 | .00625 |
18 | 1.0270 | .0050 |
20 | .09525 | .00375 |
22 | .07937 | .003125 |
24 | .0635 | .0025 |
26 | .0476 | .001875 |
28 | .0396 | .001562 |
30 | .03175 | .00125 |
Features Of Asme Sb 265 Grade 2 Plate
Titanium Sheet Hs Code
HS Code | Description |
---|---|
76169990 | 50082854-003 FRONT PLATE ASSY 2G4M-MST FRONT PLATE ASSY 2G4M-METALLICS SATIN TITANIUM (MST) (ELECTRIC COMPONENTS FOR CAP |
81089090 | TITANIUM PLATE PT 38 - 4 X 1200 X 2000MM (2 PCS) |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 2.0 X 1220 X 2440 MM - QTY10 PCS |
94036000 | WINE CART (8129# WOOD STAINLESS STEEL PLATE TITANIUM) |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 2.0 X 1000 X 2000 MM - QTY4 PCS |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 4.0 X 1000 X 2000 MM - QTY2 PCS |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 3.0 X 1000 X 2000 MM QTY-2 PCS |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 6.0 X 1000 X 2000 MM - QTY1 PCS |
81089090 | TITANIUM PLATE GR1 ASTM B265 SIZE 2.5 X 1000 X 2000 MM - QTY1 PCS |
Titanium Sheet Uses
Ti Grade 5 Polished Cold Drawn Plates Melting
Melting Point of Titanium Plate
|
1,668 °C
|
Ti Gr 2 Foil Services
Other Titanium Plate Information For Buyers
A Global supplier
We Have Supplied Various Types Of Titanium Rod Recently To Following Some Of The Countries
Titanium Plate Suppliers in India
ASTM B265 Grade 5 Sheet
Jordan, Qatar, Japan, Dubai, China, Netherlands, Istanbul- Turkey, New Zealand, Sweden, Finland, Peru, Canada, Romania, France, Argentina, Hong Kong, Spain, Malaysia, Oman, Iran, Denmark Czechia, Chile, Singapore, Greece, South Korea, Singapore, Malaysia, Jakarta, Brazil, Morocco, Egypt, Taiwan, Belgium, Dubai- UAE, Russia, Austria, United Arab Emirates (UAE), Australia
Asme Sb 265 Grade 2 Plate
Los Alamos -Mexico, Dammam -KSA, Bangladesh, Germany, Indonesia, Kuala Lumpur, Vietnam, Poland, USA, NY 12203 (USA), Turkey, Bahrain, Colombia, United States, United Kingdom (UK), Norway, Philippines, Italy, South Africa, Nigeria, Tehran -Iran, Ellington -United States, Saudi Arabia (KSA), South Africa, Thailand, Mexico, Malaysia, Kuwait, Europe, Jakarta -Indonesia, Portugal
