Incoloy 825 Round Bar

What is Incoloy 825 Round Bar?

Incoloy 825 Round Bar is designed with a chemical concentration of nickel, chromium coupled with iron alloys. The additions of molybdenum, titanium, and copper in these bars helps in enhancing the corrosion resistance of these bars. The round bars have a uniform circular cross-section that is employed in supporting different modules. The stable austenitic structure modules show resistance against sulphuric and phosphoric acids pitting and reduction process. Apart from this, they show enhanced resistance against crevice corrosion and intergranular corrosion that occurs after fabrication and welding procedures.

Comparision Between Alloy 825 Hex Bar and ASTM B425 UNS N08825 Rod

The terms bars and rods are used interchangeably in the metal industry. Both these components can be characterized by their material types shape, and other features.

  • Alloy 825 Hex Bar is a six-sided component exhibiting a polygonal cross-section. ASTM B425 UNS N08825 rod is a metallic component that can be designed with a circular or square cross-section.
  • A hex bar has a hollow opening, while a rod doesn’t possess an opening.

Alloy 825 Bar Uses

Alloy 825 Bars are versatile components exhibiting a uniform circular cross-section. These bars are employed in oil and gas extraction systems, chemical processing equipment, and nuclear fuel processing systems due to their superior corrosion resistance properties. The flexible modules are employed in the waste disposal and recycling systems, pickling services, food processing, and heating coils. Apart from this, they can also be seen in marine systems, piping sulphuric acid vessels, and so on.

2.4858 Inconel Alloy Flat Bar vs Incoloy 825 Square bar

Flat and square bars are two types of shapes that are seen across this grade. These bars can be differentiated based on their basic features.

  • 2.4858 Inconel Alloy Flat Bar is a metallic component designed with a rectangular cross-section. Incoloy 825 Square bar is designed with a square cross-sectional area.
  • A square bar has equal sides, while in flat bars, the opposite sides are equal.
  • Flat bars have lower thickness than standard square bars.

Get ASTM B425 Alloy N08825 Rod, Alloy 825 Hex Bar Manfacturer in India

Table of Content

Looking for Incoloy 825 Round Bar suppliers who offer prompt delivery in Asia? Manufacturer of Alloy 825 Round Bar in India, call us for big discount and ready sizes, check latest price of ASTM B408 Inconel Alloy 825H Rod in Mumbai

Incoloy 825 Round Bar Specifications

ASME and ASTM designationASTM B425 / ASME SB425
Marking
  • Nominal Pipe Sizes
  • Specification
  • Grade
  • Supplier / Manufacturer’s Name or Custom Logo - on request
  • Heat Number
Dimensions standardEN, AISI, JIS, BS, DIN, ASTM, ASME
Size in mm
5 To 500 millimeter
Dual certified Manufacturers Dual certified Alloy 625 Round Bar Manufacturers in India, accordance to certify ASME SB446 and ASTM B446 American specifications
Available Diameter0.1 to 100 millimeter
Stocking Length100 To 3000 millimeter Long or Above than it
FinishesRough, BA Finish, Polished, NO.4 Finish, Black, Matt Finish, Bright, Turned
find ToleranceH8, H10, H12, H11, H13K9, K11, K10, H9, K12 or as per clients’ specification
Basic FormHex (A/F), Square, Ingot, Rectangle,Forging, Billet, Round
Incoloy 825 Round Bar Manufacturers in India

Length of Alloy 825 Round Bar

  • Metric system: standard length is 9 - 12 metres
  • USA : 40 feet

Manufacturer & Supplier Of GOST ЭП703 Hex Bar, Alloy 825 Bar In India

UNS N08825 Bright Bars, Hot Rolled Alloy 825 Round Bar Check 2.4858 Nickel Flat/Square Bars Price In India

ASTM B408 Inconel Alloy 825H Rod Price List

DescriptionPrice in USPrice in India
cold drawn steel bars 10mm 12mm 16mm ASTM B425 incoloy 825 UNS N08825 alloyUS $21.00 / Kilogram1562.52
Nickel incoloy 825 uns n08825 alloy steel round barsUS $20.00-$45.00 / Kilogram1488.11 - 3348.25
Incoloy 825 Round barsUS $35.00 / Kilogram2604.19
Incoloy 825 custom forged round bars N08825US $20.00-$22.00 / Kilogram1488.11 - 1636.92
cold drawn steel round bars 10mm 12mm 16mm ASTM B425 incoloy 825 alloy steel barsUS $9.90-$16.90 / Kilogram736.61 - 1257.45
825 Alloy Steel Round barsUS $10.00-$15.00 / Kilogram744.06 - 1116.08

Surface Finish of Alloy 825 Bar

Cold drawnCDPolishedP
Bright drawnBDSlit rolled edgeSRE
Centreless groundCGHot finishedHF
Cold finishedCFHot rolled annealed and pickledHRAP
Peeled and turnedP&TRough turned/peeledRT
Smooth turnedSTPeeled and reeledPR

Well-known Manufacturer Of Nickel 825 Cold Drawn Round Bars in India. For final UNS N08825 Flat Bars Price List Please Call on +91 22 6636 3099.

ASTM Standard of Nickel 825 Cold Drawn Round Bar

ASTM Standard of Nickel 825 Cold Drawn Round Bar

Tolerance of Inconel 825H Bar

Tolerances for Cold Drawn Alloy 825 Round Bar
Shape / SectionSize, diameter or width across flatsPermitted variation
mmmm
Round≥6 ≦ 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 100		+ 0 to - 0.070
+ 0 to - 0.085
+ 0 to - 0.100
+ 0 to - 0.120
+ 0 to - 0.140
Flat (thickness)< 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80		+ 0 to - 0.110
+ 0 to - 0.130
+ 0 to - 0.250
+ 0 to - 0.350
Flat (width)< 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 100
> 100 ≦ 130
> 130 ≦ 160
> 160 ≦ 320		+ 0 to - 0.110
+ 0 to - 0.130
+ 0 to - 0.160
+ 0 to - 0.190
+ 0 to - 0.220
+ 0 to - 0.350
+ 0 to - 1.00
+ 1.00 to - 1.00
Square and
hexagon		≥ 6 ≦ 18
> 18 ≦ 30
> 30 ≦ 50
> 50 ≦ 80
> 80 ≦ 105		+ 0 to - 0.090
+ 0 to - 0.110
+ 0 to - 0.130
+ 0 to - 0.160
+ 0 to - 0.250

PED Certified UNS N08825 Square Bars Manufacturers in Mumbai, India, Dimensions Of Inconel 825 Round Bars In MM.

2mm, 3mm, 6mm ASME SB425 Inconel Alloy 825 Cold Drawn And Hot Rolled Bars Sizes. Huge Stock of 825 Incoloy Rectangle Bar in Mumbai

Alloy 825 Round Bar Sizes

US BarsMetricJapaneseCanadian/ASTM
Diameter(Inch) Bars SizeDiameter (millimeter) Bars SizeDiameter (millimeter)Round Bars SizeDiameter (millimeter2)Bars Size
0.250#2556610010M
0.375#35.55.5101020015M
0.500#466131330020M
0.625#577161650025M
0.750#688191970030M
0.875#7992222100035M
1.000#810102525150045M
1.125#911112929250055M
1.250#1012123232
1.375#1114143535
1.500#1216163838
1.625#1318184141
1.750#1420204444
1.875#1522224848
2.000#1625255151
2.250#1828285757
3232
3636
4040
4444
5050

Other Types of Incoloy 825 Bar

Incoloy 825 Bar Types

Nickel Alloy 825H Round Bar Weight

Round bars Sizekilogram / Meterkilogram / FootSizekilogram / Meterkilogram / FootSizekilogram / Meterkilogram / Foot
1/8"0.0620.01922 millimeter2.9790.9083 to 1/4"41.99612.800
3 millimeter0.0550.01720 millimeter2.4700.7533"35.76210.900
4 millimeter0.0980.03024 millimeter3.5431.0803 to 3/4"55.78017.001
5/32"0.0950.0297/8"3.0380.9263 to 1/2"48.77214.850
5 millimeter0.1540.0471"3.9701.2104 to 1/4"72.24921.908
3/16"0.1410.04325 millimeter3.8711.1804"63.34019.306
6 millimeter0.2230.06827 millimeter4.4901.3684 to 3/4"90.24927.366
7/32"0.1900.05826 millimeter4.1701.2714 to 1/2"80.34024.4487
7 millimeter0.2980.09130 millimeter5.5481.6915 to 1/2"121.00036.690
1/4"0.2490.0761 to 1/8"5.0331.5345"99.94030.461
8 millimeter0.3980.12032 millimeter6.3141.8946 to 1/2"167.63051.093
5/16"0.3870.1181 to 1/4"6.3491.9246"143.90043.860
3/8"0.5570.17035 millimeter7.5532.3907 to 1/2"225.00068.226
9 millimeter0.4980.1521 to 3/8"7.5502.3037"196.00059.432
11 millimeter0.7480.22838 millimeter8.9032.79210"397.140121.048
10 millimeter0.6200.18936 millimeter7.9992.4388"254.5577.586
12 millimeter0.8890.27140 millimeter9.8723.009
7/16"0.7610.2321 to 1/2"8.9512.715
13 millimeter1.0430.3181 to 3/4"12.1793.712
1/2"0.9940.3031 to 5/8"10.4493.200
9/16"1.2560.3831 to 7/8"13.9774.260
14 millimeter1.2070.36845 millimeter12.5553.807
5/8"1.5510.47350 millimeter15.4144.698
15 millimeter1.3910.42448 millimeter14.2054.330
17 millimeter1.7910.5432 to 1/8"17.9635.475
16 millimeter1.5780.4812"15.9064.848
18 millimeter2.0010.61060 millimeter22.2056.768
11/16"1.8800.5732 to 1/4"20.1286.135
3/4"2.2370.6822 to 3/8"22.4356.838
2 to 1/2"24.8567.576
2 to 5/8"27.4098.354
2 to 3/4"30.0839.169

Inconel 825 Round Bar Chemical Composition

Incoloy GradeNiCrFeMbTiCuMnCSAlSi
Incoloy 82538.0 – 46.019.5 – 23.522.0 min2.5 – 3.50.6 – 1.21.5 – 3.01.0 max0.05 max0.03 max0.2 max0.5 max

Alloy NCF 825 Cold Rolled Round Bar Mechanical Properties

DensityMelting PointTensile StrengthYield Strength (0.2%Offset)Elongation
8.14 g/cm31400 °C (2550 °F)Psi – 80,000 , MPa – 550Psi – 32,000 , MPa – 22030 %

Check Equivalent Of Alloy NCF 825 Rod and Incoloy 825h Round Bars Supplier & Manufacturers In Mumbai, India.

Incoloy 825h Round Bar Equivalent

STANDARDWERKSTOFF NR.UNSGOSTAFNORJISBSENOR
Incoloy 8252.4858N08825ЭП703NFE30C20DUMNCF 825NA 16NiCr21MoXH38BT

Condition of AMS 5766 Polished Bar

ANNAnnealed
H&THardened and tempered.
PHPrecipitation hardened.

Melting Point of NA 16 Black Bar

ElementIncoloy 825
Melting Point1400 °C (2550 °F)

Incoloy 825 Round Bar Types

Incoloy 825 Bar
Incoloy 825 Bar
Incoloy 825 Round Bar
Incoloy 825 Round Bar
Nickel Incoloy 825 UNS N08825 Alloy Steel Round Bar
Nickel Incoloy 825 UNS N08825 Alloy Steel Round bars
Alloy 825 Round Bar
Alloy 825 Round Bar
Incoloy 825 Flat Bar
Incoloy 825 Flat Bar
Incoloy 825 Square Bar
Incoloy 825 Square Bar
Alloy 825 Rod
Alloy 825 Rod
Incoloy 825 Hex Bar
Incoloy 825 Hex Bar
Incoloy 825 Rod
Incoloy 825 Rod
Accept all small/ Large Orders DIN 2.4858 Threaded, Forged And Bright Bar Stock, Hot Rolled Incoloy 825 Bar, Potential Alloy 825 Rod, available in a wide range of shapes & sizes

Alloy 825 Rod Stock

Alloy UNS N08825 Hex Cold Drawn BarsIncoloy 825 Nickel Alloy Triangular Rod
Alloy 825 Nickel Threaded Rod M12Alloy 825 Incoloy Threaded Bars
2.4858 Incoloy 825 Rectangular RodIncoloy 825 Grade Polished Bars
Alloy 825 Incoloy Square Rod BlackIncoloy 825 Black Bars
Alloy 825 Nickel Rectangular Rod BrightIncoloy 825 Din 2.4858 Bright Rod Hollow
Incoloy 825 Din 2.4858 Rectangular Rod BlackAlloy Incoloy 825 Bright Rod Hex
Incoloy UNS No 8825 Rectangular Rod Cold DrawnAlloy UNS N08825 Polished Square Rod
Alloy 825 Incoloy Hex Rod BlackAlloy Incoloy 825 Square Bars

Incoloy 825 Hex Bar Sizes

Wt per Foot of hex barsSize in InchesWt per Inch
0.01801/4″2.160
0.01043/16″1.248
0.06003/8″4.920
0.02905/16″3.480
0.07401/2″8.880
0.05607/16″6.72
1.1505/8″13.80
0.09309/16″11.16
1.6603/4″19.92
1.39011/16″16.68
2.3007/8″27.60
2.60015/16″31.20
1.95013/16″23.40
3.301-1/16″39.60
2.901″34.80
4.6001-1/4″55.20
3.7001-1/8″44.40
5.6001-3/8″67.20
5.1001-5/16″61.20
6.6001-1/2″79.20
6.1001-7/16″73.20
26.533″318.36
9.0301-3/4″108.36
7.8001-5/8″93.60
18.422-1/2″221.04
11.802″141.60
10.04001-7/8″124.80
16.9202-3/8″203.04
14.9202-1/4″179.04

Incoloy 825 Square Bar Size Chart

Size in milimeterAverage Weight
KG/FTKG/MTR
12 x 120.0301.010
10 x 100.0200.080
16 x 160.0602.000
14 x 140.0501.050
20 x 201.0003.014
17 x 170.0692.027
32 x 322.0408.000
63 x 639.05031.020
25 x 251.0504.090
42 X 424.02213.085
40 x 403.08012.060
53 X 536.07222.005
50 x 506.00019.060
56 x 567.05024.060

Incoloy 825 ASTM B408 Threaded Bar Density

ElementIncoloy 825
Density8.14 g/cm3

Sizes of Incoloy 825 Flat Bar

metric weights and sizes
Colour Codebar Size(meters) LengthKilogram per Meter
Blue13 x 36.00.031
Blue10 x 30.024
Blue16 x 30.038
Orange13 x 50.046
Red16 x 81.03
Orange16 x 50.064
Orange20 x 50.081
Blue20 x 30.048
Yellow20 x 101.61
White20 x 60.097
Orange25 x 51.01
Blue25 x 30.060
Red25 x 81.61
White25 x 61.21
Pink25 x 122.41
Yellow25 x 102.01
Orange32 x 51.29
Blue32 x 30.077
Red32 x 82.06
White32 x 61.55
Pink32 x 123.09
Yellow32 x 102.58
Blue40 x 30.097
White40 x 61.93
Orange40 x 51.61
Yellow40 x 103.22
Red40 x 82.58
Grey40 x 165.15
Pink40 x 123.86
Blue50 x 31.21
Green40 x 206.14
White50 x 62.41
Orange50 x 52.01
Yellow50 x 104.02
Red50 x 83.22
Grey50 x 166.44
Pink50 x 124.83
Purple50 x 2510.01
Green50 x 208.05
Orange65 x 52.62
Blue65 x 31.57
Red65 x 84.18
White65 x 63.14
Pink65 x 126.28
Yellow65 x 105.23
Green65 x 2010.05
Grey65 x 168.37
Orange75 x 53.02
White75 x 63.62
Purple65 x 2513.1
Yellow75 x 106.04
Red75 x 84.83
Grey75 x 169.66
Pink75 x 127.24
Purple75 x 2515.1
Green75 x 2012.1
Orange90 x 53.62
Yellow75 x 4024.1
White90 x 64.35
Red90 x 85.79
Yellow90 x 107.24
Pink90 x 128.69
Orange100 x 54.02
White100 x 64.83
Red100 x 86.44
Yellow100 x 108.05
Pink100 x 129.66
Grey100 x 1612.9
Green100 x 2016.1
Purple100 x 2520.01
Green100 x 5040.02
White110 x 65.31
Red110 x 87.08
Yellow110 x 108.85
Pink110 x 1210.06
Orange130 x 55.23
White130 x 66.28
Red130 x 88.37
Yellow130 x 1010.05
Pink130 x 1212.6
Grey130 x 1616.7
Green130 x 2020.09
Purple130 x 2526.2
Orange150 x 56.04
White150 x 67.24
Red150 x 89.66
Yellow150 x 1012.1
Pink150 x 1214.5
Grey150 x 1619.3
Green150 x 2024.1
Purple150 x 2530.01
Green150 x 5060.04
Orange180 x 57.24
White180 x 68.69
Yellow180 x 1014.5
Pink180 x 1217.4
Grey180 x 1623.2
Green180 x 2029.0
Purple180 x 2536.2
White200 x 69.66
Red200 x 812.9
Yellow200 x 1016.1
Pink200 x 1219.3
Grey200 x 1625.7
Green200 x 2032.2
Purple200 x 2540.03
White250 x 612.1
Red250 x 816.1
Yellow250 x 1020.01
Pink250 x 1224.1
Grey250 x 1632.2
Green250 x 2040.02
Purple250 x 2550.03
White300 x 614.5
Red300 x 819.3
Yellow300 x 1024.1
Pink300 x 1229.0
Grey300 x 1638.6
Green300 x 2048.3
Purple300 x 2560.04

DIN 2.4858 Bright Bar Gravity

Specific Gravity
8.14 g/cm3

Buy Inconel 825H Bar Directly From Largest Manufacturers In Mumbai, Check Nickel Alloy 825H Round Bar Stock

Documentation of Alloy 825HT Round Bar

  • Commercial Invoice which includes HS Code
  • Packing List including net weight and gross weight, number of boxes, Marks and Numbers
  • Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
  • Fumigation Certificates
  • Raw Material Test Reports
  • Material Traceability Records
  • Quality Assurance Plan (QAP)
  • Heat Treatment Charts
  • Test Certificates certifying NACE MR0103, NACE MR0175
  • Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2
  • Guarantee Letter
  • NABL approved Laboratory Test Reports
  • Welding Procedure Specification/Procedure Qualification Record, WPS/PQR
  • Form A for the purposes of the Generalized System of Preferences (GSP)
ASTM B425 Gr 825 Hollow Bar, BS 3076 NA16 Forged Bars, 16mm cold rolled Nickel Alloy 825HT Round Bar. View Alloy 825 Incoloy Hexagon Bars Prices and Dimension

Incoloy 825 Rod Dimension

Diameter or
Width
(milimeter)		Sectional Arearound bars Weight per meterPerimeter
Round
(centimeter²)		Square
(centimeter²)		Round
(kilogram)		Square
(kilogram)		Round
(centimeter)		Square
(centimeter)
5.00.200.250.150.201.572.0
5.50.240.300.190.241.782.2
6.00.280.360.220.281.882.4
7.00.380.490.300.382.202.8
8.00.500.640.390.502.513.2
9.00.640.810.500.642.833.6
100.791.000.630.733.144.0
110.951.210.750.953.464.4
121.131.440.891.133.774.8
141.541.961.211.544.405.6
162.012.561.582.015.036.4
182.543.242.002.545.657.2
203.144.002.473.146.288.0
223.804.842.983.806.918.8
254.916.253.854.917.8510.0
286.167.844.836.158.8011.2
328.0410.246.318.0410.0512.8
3610.1812.967.9910.1711.3114.4
4012.5716.009.8612.5612.5716.0
4515.9020.2512.4915.9014.1418.0
5019.6425.0015.4119.6215.7120.0
5624.6331.3619.3424.6217.5922.4
6331.1736.6924.4731.1619.7925.2
7139.5950.4131.0839.5722.3128.4
8050.2764.0039.4650.2425.1332.0

Get instant delivery Of 20mm AMS 5766 Polished Bar , Dimension Chart Of UNS N08825 Inconel Rectangular Bar, Incoloy 825 Round Bar Manufacturer In Mumbai. India.

UNS N08825 Inconel Hollow Bar Sizes

Size in Mmkg per meterSize In MMkg per meter
20*20*2.01.1225*25*2.01.43
25*25*1.51.0620*20*2.51.35
25*25*2.51.7430*30*2.52.14
30*30*2.01.6825*25*3.02.04
30*30*3.02.5140*40*1.51.81
40*40*2.02.3150*50*1.52.28
40*40*3.03.4540*40*4.04.46
40*40*5.05.4040*40*2.52.92
50*50*2.02.9350*50*2.53.71
50*50*3.04.3960*60*3.05.34
50*50*5.06.9750*50*4.05.72
60*60*4.06.9760*60*5.08.54
60*60*6.09.4580*80*3.07.22
70*70*3.67.4670*70*5.010.11
70*70*6.312.5090*90*5.013.30
75*75*3.07.0780*80*5.011.70
80*80*3.68.5970*70*3.06.28
80*80*6.013.9090*90*3.08.01
90*90*3.69.7270*70*815.30
90*90*6.015.76100*100*4.012.00
100*100*3.08.9690*90*8.020.40
100*100*5.014.80120*120*6.322.30
100*100*6.016.19120*120*1034.20
100*100*1027.90120*120*518.00
120*120*6.021.30100*100*5.014.80
120*120*8.027.90100*100*8.022.90
120*120*1235.8120*120*12.541.60
140*140*5.021.10140*140*6.326.30
140*140*832.90140*140*1040.40
140*140*12.549.50150*150*5.022.70
150*150*6.328.30150*150*8.035.40
150*150*1043.60180*180*1053.00
150*150*1666.40180*180*6.334.20
180*180*527.40150*150*1666.40
180*180*843.00150*150*12.553.40
180*180*12.565.20200*200*635.8
200*200*530.50180*180*1681.40
200*200*6.338.2250*250*860.50
200*200*1059.30250*250*12.592.60
200*200*1691.50250*250*6.348.10
200*200*848.00250*250*1075.00
200*200*12.573.00250*250*16117.00
300*300*6.357.90400*400*16192
300*300*1057.90350*350*12.5132.00
300*300*12.5112.00300*300*16142.00
350*350*885.70350*350*10106.00
300*300*890.70350*350*16167.00
400*400*10122.00400*400*12141.00
400*400*12.5152.00300*300*873.10

Other Products

A Global supplier

Check our material dispatch in the following countries

Incoloy 825 Round Bar Manufacturers in India

Incoloy 825 Round Bar Manufacturers in India

Alloy 825 Round Bar

Alloy 825 Round Bar


Taiwan, Iran, Dubai, Turkey, Poland, United Kingdom (UK), France, Peru, Netherlands, Kuala Lumpur, Indonesia, Nigeria, Czechia, NY 12203 (USA), Brazil, Tehran -Iran, Jakarta -Indonesia, Saudi Arabia (KSA), Japan, Vietnam, Malaysia, Spain, Russia, Argentina, Germany, Austria, Canada, Italy, Philippines, South Africa, Malaysia, Hong Kong, Dubai- UAE, Jordan, Dammam -KSA, Singapore

ASTM B408 Inconel 825 Round Bar

ASTM B408 Inconel 825 Round Bar


United States, Greece, Morocco, Los Alamos -Mexico, Australia, United Arab Emirates (UAE), New Zealand, Europe, Portugal, Mexico, Egypt, Bangladesh, Kuwait, South Africa, Istanbul- Turkey, Belgium, Denmark Sweden, Finland, Ellington -United States, Bahrain, Qatar, Chile, Malaysia, Oman, China, Colombia, USA, South Korea, Jakarta, Romania, Norway, Singapore, Thailand

X
